Panasonic Modular High-speed Multi-functional Placement Machine CM602
Category: PANASONIC  Publish Time: 2016-03-05 12:12

Panasonic Modular High-speed Multi-functional Placement Machine CM602
•One platform solution for any kind of production • APC-capable (Adaptive Process Control)—adapting placement of 01005s down to 1.6mil spacing • Linear motor drive increases reliability and reduces maintenance • Compatible with other CM-series equipment

CM602


MODEL NO.
NM-EJM8A

PCB DIMENSIONS
 Min L × W
  to 50 mm × 50 mm


Max L × W
  510 mm × 460 mm

HEAD TYPE
HIGH-SPEED (12 Nozzles)
  HIGH-FLEXIBILITY (8 Nozzles)
 MULTI-FUNCTION (3 Nozzles)

Maximum speed
  0.036 s/chip (for Type A-2 head)
  0.048 s/chip (for Type A-0 head)
 0.18 s/QFP (for Type B-0 head)

Placement accuracy
  ±40 μm/chip (Cpk≥1)
 ±40 μm/chip, ±35 μm/QFP 24 mm to 32 mm
±50 μm/QFP <24 mm (Cpk≥1)

 ±35 μm/chip (Cpk≥1)
COMPONENT DIMENSIONS (mm)

 0402 (01005") chip*6 to L 12 x W 12
  0603 (0201") chip to L 32 x W 32
  0603 (0201") chip to L 100 x W 90
PCB EXCHANGE TIME
0.9s (Board length up to 240 mm under optimum conditions)

ELECTRIC SOURCE*1
3-phase AC 200 V, 4.0 kVA

PNEUMATIC SOURCE*2
0.49 MPa, 170 L/min (A.N.R.)

DIMENSIONS*2
W2,350 mmXD2,290 mmX1,430 mm

MASS
3,400 kg
